sulzer
MixCoat Mixer
Mixpac™
MixCoat Mixer
The MixCoat mixers from medmix Switzerland AG are ideal for the dispensing of 2C adhesives and sealants. The static mixers can be used with cartridges that feature the MixCoat-System Mixpac™ connection. These mixers ensure that both components combine to form a homogeneous mixture and enable the spraying function through compressed air. There are options for the 0° and 90° configurations as well as the MFQA mixers with an angled tip, which facilitate coating work in intricate geometries.
| Manufacturer: | medmix Switzerland AG |
| Connection: | MixCoat-System Mixpac™ |
Variants of MixCoat Mixer
| Variant | Type | Application Type | Mix Cycles | Mixture Ratios | Tip | Ø | Length | Art.-No. | |
|---|---|---|---|---|---|---|---|---|---|
| MFQ 07-18C-12 (high flow) | Type: Quadro | Application Type: Spray Application | Mix Cycles: 18 | Mixture Ratios: 1:1, 2:1, 3:1, 4:1 | Tip: straight | Diameter: 8mm | Length: 128mm | Art.-No.: ITR5062 | |
| MFQ 07-18C-06 (high flow) | Type: Quadro | Application Type: Spray Application | Mix Cycles: 18 | Mixture Ratios: 1:1, 2:1, 3:1, 4:1 | Tip: straight | Diameter: 8mm | Length: 128mm | Art.-No.: ITR4447 | |
| MFQ 08-24C-06 (high flow) | Type: Quadro | Application Type: Spray Application | Mix Cycles: 24 | Mixture Ratios: 1:1, 2:1, 3:1, 4:1 | Tip: straight | Diameter: 9mm | Length: 168mm | Art.-No.: ITR2332 | |
| MFQ 08-24C-07 (medium flow) | Type: Quadro | Application Type: Spray Application | Mix Cycles: 24 | Mixture Ratios: 1:1, 2:1, 3:1, 4:1 | Tip: straight | Diameter: 9mm | Length: 168mm | Art.-No.: ITR2331 | |
| MFQ 08-24C-13 (medium flow) | Type: Quadro | Application Type: Spray Application | Mix Cycles: 24 | Mixture Ratios: 1:1, 2:1, 3:1, 4:1 | Tip: straight | Diameter: 9mm | Length: 168mm | Art.-No.: ITR4220 | |
| MFQA 08-24C-07 (medium flow) | Type: Quadro | Application Type: Spray Application | Mix Cycles: 24 | Mixture Ratios: 1:1, 2:1, 3:1, 4:1 | Tip: straight | Diameter: 9mm | Length: 178mm | Art.-No.: ITR2333 |
